Retractable nipple STARK.airtec with compensation

S5000-013

Product description

Retractable nipple STARK.airtec with equaliser
Retractable nipple suitable for all fast closing clamps of the STARK.airtec family

Features:
- function: with equaliser
- collar: 25 mm
- collar height: 4.8 mm
- length: 27.5 mm
- fastening: for screw M10 DIN 912 through or fastening to M12 internal thread
- weight: approx. 0.1 kg

Scope of delivery:
- 1× retractable nipple

Documents:
- catalogue: WM-020-288
- installation according to datasheet: D029-4
- operating manual: WM-020-168

Downloads

  • Product catalogue

    Product catalogue

    WM-020-288

    STARK-airtec_15-03_web

    pdf / 3.83 MB

  • Operating manual

    Operating manual

    WM-020-168

    BA STARK.airtec

    pdf / 1.71 MB

  • CAD model

    STARK_S5000-013_B

  • Product Sheet

    Product Sheet

    Product Sheet

    pdf

  • Installation sheet

    Installation sheet

    STARK_D029-4_B

    pdf / 0.12 MB
